81800V186
Omni directional,Automobile antenna,High Performance
| 频段范围 | 2250MHz-2300MHz/5500MHz -5850MHz | ||
| 阻抗 | 50 (Ω) | ||
| 驻波比 | ≤3.5 / ≤2.0 | ||
| 辐射方向 | Omni directional | ||
| 极化形式 | Vertical | ||
| 峰值增益 | 2.34dBi / 5.90dBi | ||
| 测试条件 | passive test | ||
| 无源效率 | ≥35% / ≥53% | ||
| 天线类型 | Automobile antenna | ||
| 连接器类型 | USS RF 1 | ||
| 射频线型号 | OD1.13mm White | ||
| 尺寸 | 40.35*12*3mm | ||
| 盐雾测试 | 48 H | ||
| 工作温度 | -40℃～+80℃ | ||
| 存储温度 | -40℃～+85℃ | ||
